LIGNE DE PURIFICATION PRIMAIRE VNP-10
PRODUIT
Vegetable oil after oil extraction
CARACTÉRISTIQUES
Color number (Iodine number, mg), no more
100
Mass fraction of phosphorus-containing substances in terms of stearooleolecithin,%, no more
4,0
Mass fraction of phosphorus-containing substances in terms of P2O5,%, no more
0,4
Productivity at oil temperature 25 ... 40 ° С, max t / day
5
Productivity at oil temperature 75 ... 90 ° С, max t / day
15
Working pressure, MPa (bar)
0,6 (6,0)
Length, mm
7557
Width, mm
2706
Height, mm
3934
Installed power, kW
20,7
Weight, kg
5530
This line is designed for pre-purification of vegetable oils after mechanical, pressing wringing.
Product quality after processing: complies with the DSTU 4534-2006 standard
The line capacity depends on the oil inlet temperature:
The advantage over settling the oil is a much better separation of vegetable oil from mechanical impurities.
SÉQUENCE DE TRAVAIL
1 time in 2 months:
Clean the filter plates under running hot water or steam.
Install them vertically (or at a slight angle) on a wooden stand so as not to damage the walls and clean them from the outside with a stream of water at a temperature of 90 … 100 ° C or steam with a temperature of 135 … 140 ° C
