| Model | Screw diameter, mm | Productivity, t/h (grain) | Conveyor length, m | Drive power, kW |
|---|---|---|---|---|
| BK-160 | 160 | 3,4 – 6,8 | up to 30 | 1,1 – 2,2 |
| BK-200 | 200 | 6,6 – 13,1 | up to 30 | 1,1 – 4,0 |
| BK-250 | 250 | 12,8 – 25,6 | up to 30 | 2,2 – 7,5 |
| BK-320 | 320 | 26,8 – 53,6 | up to 30 | 4,0 – 11,0 |
| BK-400 | 400 | 52,4 – 104,8 | up to 30 | 7,5 – 18,5 |
The pitch of the screw conveyor is 100 mm (up to 30 m)
Designed for horizontal transportation or at an angle of up to 20° to the horizontal of grain, flour, bran and other bulk products with a bulk density of 250–750 kg/m³.
Used for continuous operation in technological lines of mills, feed mills and other grain processing enterprises.
Loading and unloading nozzles can be installed at any point of these screw conveyors.
Depending on the technological task, the conveyor can be equipped with a screw with a multi-directional winding:
- For product dilution – when the raw material is fed to the center and moved to the opposite edges of the conveyor.
- For product reduction – when the raw material is loaded from the edges of the conveyor and moved to the center (for example, to a common discharge pipe).
